4F Tactical Armored Fiber Cable 4.5mm With TPU Jacket Waterproof Corrosion Resistant

Product Categories

Shenzhen Hicorpwell Technology Co., Ltd

Contact Now

4F Tactical Armored Fiber Cable 4.5mm With TPU Jacket Waterproof Corrosion Resistant

Name: 4F Tactical Armored Fiber Cable 45mm With TPU Jacket Waterproof Corrosion Resistant
Brand: HICORPWELL
Price: 1 USD

4F Tactical Armored Fiber Cable 4.5mm With TPU Jacket Waterproof Corrosion Resistant Manufactures

Brand Name : HICORPWELL

Model Number : Outdoor Tactical IP67 PDLC Connectors

Certification : IEC 60794-2-10/11

Place of Origin : China

MOQ : 10sets

Price : negotiation

Payment Terms : Western Union, L/C, T/T

Supply Ability : 5000pcs Per Week

Packaging Details : Max 100m/ per reel for 5.0 mm OD cable

Cable Type : Tactical IP67 PDLC Waterproof Connectors

Connectors : Customized or LC Connectors

Paintcoat Color : Black

Cable Purpose : Broadcast Media Usage

Length : Per Reel.100m -300m

Application : Outdoor Communication

Contact Now

Connector4F Armoured tactical fiber 4.5mm cable with TPU jacket Fiber Optic Components

Tactical Connector Designed for military field fiber optic cable supporting, neutral bayonet locking

structure can be realized head and seat, head and head, seat and seat fast any connection.

With multi-core once connected and blind insertion; connection loss, high reliability; rugged, waterproof,

dustproof, resistance to harsh environments, etc.,

can be used in a variety of optical fiber communication network field army, military computer systems,

airborne or ship borne equipment, repair and other outdoor optical cable system temporary connection.

Product specifications :

2 core, 4 core, 6-core, 8-core, 12 core.

Products are mainly used for:

military emergency communications, broadcast television, emergency rush through optical fiber

communications, mining, oil and so on.

Features

● Using plug connection technology for fast connections.

● Blind Pin keys to position the multi-core fiber design to ensure the correctness and a blind plug connection.

● Connector plug and socket comes with dust cover, ensure the quality of the connection.

● Has a corrosion-resistant, waterproof, dustproof, etc.

Applications

● Tactical Communication Connection

● Oil, Mine Communication Connection

● Remote Wireless Base Station

● CCTV System

● Fiber Sensor

● Railway signal Control Application

● Intelligent Power Station Communication

Product Parameters

Name	Parameters	Name	Parameters
IL(SM)	≤0.8dB	Cable OD.	5.0mm or 4.0mm
IL(MM)	≤0.5dB	Outer Sheath	TPU
RL(SM)	≥50dB	Anti-push Unit	KEVLAR
Plug	≤500N(Main Cable)	Fiber Type	9/125, 50/125, 62.5/125
Socket	≤100N(Branch Cable)	Fiber Outer	900um fiber
Operation Tem.	-40℃～85℃	Tensile Strength	Short term:120N/ Long term:600N
IP Class	IP67
RHoS	Comply with RHoS

4F Tactical Armored Fiber Cable 4.5mm With TPU Jacket Waterproof Corrosion Resistant
