SMA905 Reflector Probe Quartz Fiber Beam 6.35mm Probe Y Probe 6+1 Fiber

Name: SMA905 Reflector Probe Quartz Fiber Beam 635mm Probe Y Probe 61 Fiber
Brand: HICORPWELL
Price: 1 USD

SMA905 Reflector Probe Quartz Fiber Beam 6.35mm Probe Y Probe 6+1 Fiber Manufactures

Brand Name : HICORPWELL

Model Number : 50um 100um 200um 400um Fiber

Certification : IEC 60794-2-10/11

Place of Origin : China

MOQ : 100CM

Price : negotiation

Payment Terms : Western Union, L/C, T/T

Supply Ability : 1000KM Per Month

Packaging Details : Standard length: Customized (as per your requirements)

Core Diameter (um) : 50 105 200 300 400 600

Core Material : Quartz fiber optics

Connectors : Probe/SMA905/906

FIBER OPTIC BUNDLES Range : 200-1100nm

Keyword : SMA905 Reflector Probe Quartz Fiber Beam

Operating Temperature : --40℃~+85

Coating Material : Acrylate Coating

Cladding Dia （um) : 125 125 220 330 440 660

Contact Now

SMA905 Reflector Probe Quartz Fiber Beam 6.35mm Probe Y Probe 6+1 Fiber

SMA Fiber

All standard connectors (SMA 905, SMA 906, ST, FC) are available—or custom ferrules,

machined in-house to your specifications. Refer to individual fiber data sheets for more information

and to determine the best fiber for your application. NA is measured at the 95% intensity angle.

We strive to ensure the accuracy of all information provided; however, we imply no warranties and

disclaim any liability in connection with the use of this information.

Precision SMA905 fiber optic connector or with an air gap protection improved metal SMA-905 connector,

end precision grinding large core diameter fiber optic energy, to meet the general semiconductor laser / modules

and output energy of the laser transmission in a low-power solid-state lasers;

connection head of internal processes can be used without glue ring protection technology,

further enhance the cooling effect and increased energy fiber life, meet laser welding,

cutting and other high-power transmission needs.

Parameter	Specification
Core Diameter(μm)	50 105 200 300 400 600
CladdingDiameter(um)	125 125 220 330 440 660
Core Material	Pure Quartz
Cladding Material	Quartz
Coating Material	Acrylate Coating
Core:Cladding	1:1.1 or 1:1.05
NA(Numerical Aperture)	0.20-0.22
Working Band(nm)	200-1100
Fiber Length(M)	Customized
Operating Temperature (℃)	--40℃~+85

SMA905 Reflector Probe Quartz Fiber Beam 6.35mm Probe Y Probe 6+1 Fiber
